Horizontal Centrifugal Pump
> CN ANSI Process Pump
|
Goulds 3196 Pump
 |
ANSI B73.1 Chemical Process Pump(100% interchangeable with Goulds 3196 Pump)
CN series chemical process pump is 100% interchangeable with GOULDS3196 series pump.
DN: 1"-10"
CN series chemical process pump is 100% interchangeable with GOULDS3196 series pump.
CN Series chemical process pumps comply with ASME B 73.1 standard. All components are interchangeable with Goulds 3196 pumps.
This line pumps is the public acknowledged the best deisgn in the chemical engineering, pulp and paper and all other process industry.
This line pumps is the public acknowledged the best deisgn in the chemical engineering, pulp and paper and all other process industry.
Long life, high reliability & efficiency,strong& compact & rational construction, stabile operation and easy installation repair.
DN: 1"-10"
Q: max 1400m3/h
H:max 142m
Media temp:-25°C~+140°C
System pressure:25bar
Material Available:
Ductile Cast Iron,SS304,SS316,Alloy 20,Titanium,CD4MCu,Monel,Nickel and Hastelloy B&C
Material Available:
Ductile Cast Iron,SS304,SS316,Alloy 20,Titanium,CD4MCu,Monel,Nickel and Hastelloy B&C
